南元泵业MHP卧式多级超高压离心泵，标配永磁变频电机，高效节能，高压力

发布时间：2026-01-08人气：329


序号	组名	型号	额定流量 (m³/h)	额定扬程 (m)	额定效率 (%)	额定转速 (rpm)	叶轮外径	叶轮级数	电机功率	额定电流	泵重量(kg)
1	MHP2	MHP2-535-28	2	535	46.2	5200	37	28	11	19.5	169
2		MHP2-550-29	2	550	46.67	5200	73	29	11	19.5	170
3		MHP2-565-30	2	565	46.09	5200	73	30	11	19.5	171
4		MHP2-585-31	2	585	47.03	5200	73	31	11	19.5	172
5		MHP2-600-32	2	600	46.4	5200	73	32	11	19.5	173
6		MHP2-620-33	2	620	45.97	5200	73	33	11	19.5	174
7		MHP2-640-34	2	640	46.32	5200	73	34	11	19.5	175
8		MHP2-660-35	2	660	46.07	5200	73	35	11	19.5	176
9		MHP2-680-36	2	680	46.37	5200	73	36	11	19.5	177
10		MHP2-695-37	2	695	46.6	5200	73	37	11	19.5	179
11		MHP2-715-38	2	715	46.47	5200	73	38	11	19.5	180
12		MHP2-735-39	2	735	46.45	5200	73	39	11	19.5	181
13		MHP2-755-40	2	755	46.68	5200	73	40	11	19.5	182
14		MHP2-770-41	2	770	46.49	5200	73	41	15	26.5	188
15		MHP2-790-42	2	790	46.21	5200	73	42	15	26.5	189
16		MHP2-810-43	2	810	46.67	5200	73	43	15	26.5	190
17		MHP2-830-44	2	830	46.74	5200	73	44	15	26.5	191
18		MHP2-850-45	2	850	46.88	5200	73	45	15	26.5	192
19		MHP2-865-46	2	865	46.6	5200	73	46	15	26.5	193
20		MHP2-885-47	2	885	46.78	5200	73	47	15	26.5	195
21		MHP2-905-48	2	905	47.09	5200	73	48	15	26.5	196
22		MHP2-925-49	2	925	46.69	5200	73	49	15	26.5	197
23		MHP2-940-50	2	940	46.38	5200	73	50	15	26.5	198
24		MHP2-960-51	2	960	46.74	5200	73	51	15	26.5	199
25		MHP2-980-52	2	980	47.12	5200	73	52	15	26.5	200
26		MHP2-1000-53	2	1000	47	5200	73	53	15	26.5	201
27	MHP3	MHP3-475-28	3	475	52.7	5200	73	28	11	19.5	169
28		MHP3-490-29	3	490	52.7	5200	73	29	11	19.5	170
29		MHP3-505-30	3	505	52.6	5200	73	30	11	19.5	171
30		MHP3-520-31	3	520	53	5200	73	31	11	19.5	172
31		MHP3-535-32	3	535	52.4	5200	73	32	11	19.5	173
32		MHP3-555-33	3	555	52.9	5200	73	33	11	19.5	174
33		MHP3-570-34	3	570	53.3	5200	73	34	11	19.5	175
34		MHP3-590-35	3	590	52.6	5200	73	35	11	19.5	176
35		MHP3-605-36	3	605	52.6	5200	73	36	11	19.5	177
36		MHP3-620-37	3	620	52.8	5200	73	37	11	19.5	179
37		MHP3-640-38	3	640	53.2	5200	73	38	11	19.5	180
38		MHP3-655-39	3	655	53.1	5200	73	39	11	19.5	181
39		MHP3-670-40	3	670	52.8	5200	73	40	11	19.5	182
40		MHP3-690-41	3	690	52.3	5200	73	41	15	26.5	188
41		MHP3-705-42	3	705	52.6	5200	73	42	15	26.5	189
42		MHP3-725-43	3	725	52.58	5200	73	43	15	26.5	190
43		MHP3-740-44	3	740	52.59	5200	73	44	15	26.5	191
44		MHP3-755-45	3	755	52.71	5200	73	45	15	26.5	192
45		MHP3-770-46	3	770	52.4	5200	73	46	15	26.5	193
46		MHP3-785-47	3	785	52.14	5200	73	47	15	26.5	195
47		MHP3-805-48	3	805	52.55	5200	73	48	15	26.5	196
48		MHP3-820-49	3	820	52.5	5200	73	49	15	26.5	197
49		MHP3-840-50	3	840	52.03	5200	73	50	15	26.5	198
50		MHP3-860-51	3	860	52.39	5200	73	51	15	26.5	199
51		MHP3-875-52	3	875	52.3	5200	73	52	15	26.5	200
52		MHP3-890-53	3	890	52.38	5200	73	53	15	26.5	201
53		MHP3-910-54	3	910	52.42	5200	73	54	15	26.5	202
54		MHP3-925-55	3	925	52.91	5200	73	55	18.5	32.6	213
55		MHP3-940-56	3	940	52.79	5200	73	56	18.5	32.6	215
56		MHP3-955-57	3	955	52.66	5200	73	57	18.5	32.6	216
57		MHP3-975-58	3	975	52.53	5200	73	58	18.5	32.6	217
58		MHP3-995-59	3	995	52.27	5200	73	59	18.5	32.6	218
59		MHP3-1005-60	3	1005	52.2	5200	73	60	18.5	32.6	219
60	MHP4	MHP4-530-29	4	530	61.7	5200	73	29	15	26.5	175
61		MHP4-545-30	4	545	61.2	5200	73	30	15	26.5	176
62		MHP4-565-31	4	565	61	5200	73	31	15	26.5	177
63		MHP4-585-32	4	585	61.3	5200	73	32	15	26.5	178
64		MHP4-605-33	4	605	61.3	5200	73	33	15	26.5	179
65		MHP4-620-34	4	620	60.8	5200	73	34	15	26.5	180
66		MHP4-640-35	4	640	61.3	5200	73	35	15	26.5	181
67		MHP4-660-36	4	660	61.2	5200	73	36	15	26.5	182
68		MHP4-680-37	4	680	61.2	5200	73	37	15	26.5	184
69		MHP4-700-38	4	700	61.5	5200	73	38	15	26.5	185
70		MHP4-715-39	4	715	60.71	5200	73	39	18.5	32.6	196
71		MHP4-730-40	4	730	60.71	5200	73	40	18.5	32.6	197
72		MHP4-750-41	4	750	60.88	5200	73	41	18.5	32.6	198
73		MHP4-770-42	4	770	61.14	5200	73	42	18.5	32.6	199
74		MHP4-785-43	4	785	60.74	5200	73	43	18.5	32.6	200
75		MHP4-805-44	4	805	60.75	5200	73	44	18.5	32.6	201
76		MHP4-820-45	4	820	60.45	5200	73	45	22	38.7	207
77		MHP4-840-46	4	840	60.79	5200	73	46	22	38.7	208
78		MHP4-860-47	4	860	60.69	5200	73	47	22	38.7	210
79		MHP4-880-48	4	880	60.43	5200	73	48	22	38.7	211
80		MHP4-895-49	4	895	60.59	5200	73	49	22	38.7	212
81		MHP4-915-50	4	915	60.27	5200	73	50	22	38.7	213
82		MHP4-935-51	4	935	60.71	5200	73	51	22	38.7	214
83		MHP4-950-52	4	950	60.82	5200	73	52	22	38.7	215
84		MHP4-970-53	4	970	60.96	5200	73	53	30	52.6	286
85		MHP4-990-54	4	990	60.3	5200	73	54	30	52.6	287
86	MHP5	MHP5-490-29	5	490	62.7	5200	73	29	15	26.5	172
87		MHP5-510-30	5	510	62.2	5200	73	30	15	26.5	173
88		MHP5-525-31	5	525	62.6	5200	73	31	15	26.5	174
89		MHP5-540-32	5	540	62.4	5200	73	32	15	26.5	175
90		MHP5-560-33	5	560	62.3	5200	73	33	15	26.5	176
91		MHP5-575-34	5	575	62.3	5200	73	34	15	26.5	177
92		MHP5-590-35	5	590	62.4	5200	73	35	15	26.5	178
93		MHP5-610-36	5	610	61.8	5200	73	36	15	26.5	179
94		MHP5-630-37	5	630	62.7	5200	73	37	15	26.5	181
95		MHP5-645-38	5	645	62.1	5200	73	38	15	26.5	182
96		MHP5-665-39	5	655	62.38	5200	73	39	18.5	32.6	193
97		MHP5-685-40	5	685	62.31	5200	73	40	18.5	32.6	194
98		MHP5-700-41	5	700	62.42	5200	73	41	18.5	32.6	195
99		MHP5-715-42	5	715	62.18	5200	73	42	18.5	32.6	196
100		MHP5-730-43	5	730	62.25	5200	73	43	18.5	32.6	197
101		MHP5-745-44	5	745	62.3	5200	73	44	18.5	32.6	198
102		MHP5-760-45	5	760	62.42	5200	73	45	22	38.7	204
103		MHP5-780-46	5	780	61.97	5200	73	46	22	38.7	205
104		MHP5-795-47	5	795	61.69	5200	73	47	22	38.7	207
105		MHP5-815-48	5	815	62.26	5200	73	48	22	38.7	208
106		MHP5-830-49	5	830	61.8	5200	73	6	22	38.7	209
107		MHP5-850-50	5	850	62.41	5200	73	50	22	38.7	210
108		MHP5-865-51	5	865	62.43	5200	73	51	22	38.7	211
109		MHP5-880-52	5	880	62.06	5200	73	52	22	38.7	212
110		MHP5-900-53	5	900	62.48	5200	73	53	30	52.6	286
111		MHP5-915-54	5	915	62.18	5200	73	54	30	52.6	287
112		MHP5-935-55	5	935	61.92	5200	73	55	30	52.6	288
113		MHP5-950-56	5	950	62.49	5200	73	56	30	52.6	289
114		MHP5-965-57	5	965	62.42	5200	73	57	30	52.6	290
115		MHP5-985-58	5	985	61.89	5200	73	58	30	52.6	291
116		MHP5-1000-59	5	1000	62.64	5200	73	59	30	52.6	292
117		MHP5-1020-60	5	1020	62.06	5200	73	60	30	52.6	293
118	MHP8	MHP8-580-32	8	580	64.38	5200	73	32	30	52.6	281
119		MHP8-600-33	8	600	64.33	5200	73	33	30	52.6	282
120		MHP8-615-34	8	615	63.52	5200	73	34	30	52.6	284
121		MHP8-630-35	8	630	64.04	5200	73	35	30	52.6	285
122		MHP8-650-36	8	650	64.33	5200	73	36	30	52.6	287
123		MHP8-670-37	8	670	64.09	5200	73	37	30	52.6	289
124		MHP8-690-38	8	690	63.63	5200	73	38	30	52.6	290
125		MHP8-705-39	8	705	63.8	5200	73	39	30	52.6	292
126		MHP8-720-40	8	720	63.72	5200	73	40	37	64.9	303
127		MHP8-740-41	8	740	63.4	5200	73	41	37	64.9	235
128		MHP8-760-42	8	760	63.86	5200	73	42	37	64.9	307
129		MHP8-780-43	8	780	63.59	5200	73	43	37	64.9	308
130		MHP8-800-44	8	800	64.14	5200	73	44	37	64.9	310
131		MHP8-820-45	8	820	63.62	5200	73	45	37	64.9	311
132		MHP8-840-46	8	840	64.42	5200	73	46	37	64.9	313
133		MHP8-860-47	8	860	63.82	5200	73	47	37	64.9	314
134		MHP8-880-48	8	880	64.17	5200	73	48	37	64.9	316
135	MHP10	MHP10-515-32	10	515	64.65	5200	73	32	30	52.6	281
136		MHP10-530-33	10	530	64.24	5200	73	33	30	52.6	282
137		MHP10-550-34	10	550	64.33	5200	73	34	30	52.6	284
138		MHP10-565-35	10	565	64.5	5200	73	35	30	52.6	285
139		MHP10-580-36	10	580	64.9	5200	73	36	30	52.6	287
140		MHP10-600-37	10	600	64.57	5200	73	37	30	52.6	289
141		MHP10-615-38	10	615	64.43	5200	73	38	30	52.6	290
142		MHP10-630-39	10	630	64.42	5200	73	39	30	52.6	292
143		MHP10-650-40	10	650	64.67	5200	73	40	37	64.9	303
144		MHP10-670-41	10	670	63.62	5200	73	41	37	64.9	305
145		MHP10-690-42	10	690	64.41	5200	73	42	37	64.9	307
146		MHP10-710-43	10	710	64.58	5200	73	43	37	64.9	308
147		MHP10-730-44	10	730	64.12	5200	73	44	37	64.9	310
148		MHP10-745-45	10	745	64.43	5200	73	45	37	64.9	311
149		MHP10-760-46	10	760	64.19	5200	73	46	37	64.9	313
150		MHP10-780-47	10	780	64.03	5200	73	47	37	64.9	314
151		MHP10-800-48	10	800	64.44	5200	73	48	37	64.9	316
152	MHP12	MHP12-640-20	12	640	64.83	5200	96.3	20	45	78.7	360
153		MHP12-670-21	12	670	65.18	5200	96.3	21	45	78.7	365
154		MHP12-700-22	12	700	65.28	5200	96.3	22	45	78.7	367
155		MHP12-735-23	12	735	64.71	5200	96.3	23	55	96	385
156		MHP12-770-24	12	770	65.13	5200	96.3	24	55	96	388
157		MHP12-800-25	12	800	65.17	5200	96.3	25	55	96	390
158		MHP12-830-26	12	830	65.06	5200	96.3	26	55	96	393
159		MHP12-865-27	12	865	64.72	5200	96.3	27	55	96	396
160		MHP12-900-28	12	900	64.93	5200	96.3	28	55	96	398
161		MHP12-930-29	12	930	65.13	5200	96.3	29	55	96	401
162		MHP12-965-30	12	965	64.96	5200	96.3	30	55	96	403
163		MHP12-1000-31	12	1000	64.97	5200	96.3	31	55	96	406
164		MHP12-1030-32	12	1030	64.91	5200	96.3	32	55	96	409
165	MHP15	MHP15-580-21	15	580	69.51	5200	92.3	21	45	78.7	365
166		MHP15-610-22	15	610	68.88	5200	92.3	22	45	78.7	367
167		MHP15-640-23	15	640	68.97	5200	92.3	23	45	78.7	370
168		MHP15-670-24	15	670	68.27	5200	92.3	24	45	78.7	373
169		MHP15-700-25	15	700	68.75	5200	92.3	25	45	78.7	375
170		MHP15-730-26	15	730	69.2	5200	92.3	26	55	96	393
171		MHP15-750-27	15	750	69.47	5200	92.3	27	55	96	396
172		MHP15-780-28	15	780	68.37	5200	92.3	28	55	96	398
173		MHP15-810-29	15	810	69.08	5200	92.3	29	55	96	401
174		MHP15-840-30	15	840	68.85	5200	92.3	30	55	96	403
175		MHP15-860-31	15	860	68.26	5200	92.3	31	75	131.2	441
176		MHP15-890-32	15	860	68.41	5200	92.3	32	75	131.2	444
177		MHP15-920-33	15	920	68.48	5200	92.3	33	75	131.2	446
178		MHP15-950-34	15	950	68.81	5200	92.3	34	75	131.2	449
179		MHP15-970-35	15	970	68.18	5200	92.3	35	75	131.2	452
180		MHP15-1000-36	15	1000	68.84	5200	92.3	36	75	131.2	454
181	MHP16	MHP16-560-21	16	560	69.8	5200	92.3	21	45	78.7	365
182		MHP16-590-22	16	590	69.71	5200	92.3	22	45	78.7	367
183		MHP16-620-23	16	620	70.34	5200	92.3	23	45	78.7	370
184		MHP16-650-24	16	650	69.52	5200	92.3	24	45	78.7	373
185		MHP16-680-25	16	680	69.5	5200	92.3	25	45	78.7	375
186		MHP16-700-26	16	700	70.36	5200	92.3	26	55	96	393
187		MHP16-730-27	16	730	69.6	5200	92.3	27	55	96	396
188		MHP16-760-28	16	760	69.64	5200	92.3	28	55	96	398
189		MHP16-790-29	16	790	69.89	5200	92.3	29	55	96	401
190		MHP16-810-30	16	810	69.72	5200	92.3	30	55	96	403
191		MHP16-840-31	16	840	69.46	5200	92.3	31	75	131.2	441
192		MHP16-870-32	16	870	69.89	5200	92.3	32	75	131.2	444
193		MHP16-900-33	16	900	70.38	5200	92.3	33	75	131.2	446
194		MHP16-920-34	16	920	70.55	5200	92.3	34	75	131.2	449
195		MHP16-950-35	16	950	70.01	5200	92.3	35	75	131.2	452
196		MHP16-980-36	16	980	70.44	5200	92.3	36	75	131.2	454
197	MHP20	MHP20-495-21	20	495	67.78	5200	92.3	21	45	78.7	365
198		MHP20-520-22	20	520	67.75	5200	92.3	22	45	78.7	367
199		MHP20-540-23	20	540	67.44	5200	92.3	23	45	78.7	370
200		MHP20-570-24	20	570	68.23	5200	92.3	24	45	78.7	373
201		MHP20-600-25	20	600	67.96	5200	92.3	25	45	78.7	375
202		MHP20-630-26	20	630	67.96	5200	92.3	26	55	96	393
203		MHP20-650-27	20	650	67.98	5200	92.3	27	55	96	396
204		MHP20-680-28	20	680	67.61	5200	92.3	28	55	96	398
205		MHP20-710-29	20	710	67.89	5200	92.3	29	55	96	401
206		MHP20-730-30	20	730	67.72	5200	92.3	30	55	96	403
207		MHP20-760-31	20	760	67.46	5200	92.3	31	75	131.2	441
208		MHP20-790-32	20	790	67.08	5200	92.3	32	75	131.2	444
209		MHP20-810-33	20	810	67.54	5200	92.3	33	75	131.2	446
210		MHP20-830-34	20	830	67.72	5200	92.3	34	75	131.2	449
211		MHP20-860-35	20	860	67.73	5200	92.3	35	75	131.2	452
212		MHP20-880-36	20	880	67.15	5200	92.3	36	75	131.2	454
213		MHP20-910-37	20	910	67.61	5200	92.3	37	75	131.2	457
214		MHP20-930-38	20	930	67.13	5200	92.3	38	75	131.2	460
215		MHP20-960-39	20	960	67.84	5200	92.3	39	75	131.2	462
216		MHP20-990-40	20	990	67.55	5200	92.3	40	75	131.2	465
217	MHP25	MHP25-340-9	25	340	65.39	5200	104.4	9	45	78.7	350
218		MHP25-375-10	25	375	65.13	5200	104.4	10	55	96	370
219		MHP25-415-11	25	415	65.24	5200	104.4	11	55	96	374
220		MHP25-455-12	25	455	65.25	5200	104.4	12	75	131.2	413
221		MHP25-490-13	25	490	64.82	5200	104.4	13	75	131.2	418
222		MHP25-530-14	25	530	65.63	5200	104.4	14	75	131.2	422
223		MHP25-570-15	25	570	65	5200	104.4	15	75	131.2	427
224		MHP25-610-16	25	610	65	5200	104.4	16	75	131.2	431
225		MHP25-650-17	25	650	65.39	5200	104.4	17	75	131.2	435
226		MHP25-690-18	25	690	65.91	5200	104.4	18	75	131.2	440
227	MHP30	MHP30-310-9	30	310	68.26	5200	104.4	9	45	78.7	350
228		MHP30-345-10	30	345	68.37	5200	104.4	10	55	96	370
229		MHP30-380-11	30	380	68.27	5200	104.4	11	55	96	374
230		MHP30-415-12	30	415	68.69	5200	104.4	12	75	131.2	413
231		MHP30-450-13	30	450	68.29	5200	104.4	13	75	131.2	418
232		MHP30-490-14	30	490	68.45	5200	104.4	14	75	131.2	422
233		MHP30-525-15	30	525	67.83	5200	104.4	15	75	131.2	427
234		MHP30-560-16	30	560	68.06	5200	104.4	16	90	157.1	456
235		MHP30-600-17	30	600	68.77	5200	104.4	17	90	157.1	460
236		MHP30-640-18	30	640	68.12	5200	104.4	18	90	157.1	465
237	MHP50	MHP50-500-10	50	500	73.45	5200	118.2	10	110	191.8	627
238		MHP50-550-11	50	550	73.82	5200	118.2	11	132	230	652
239		MHP50-600-12	50	600	73.93	5200	118.2	12	132	230	658
240		MHP50-650-13	50	650	73.51	5200	118.2	13	160	279	678
241	MHP50	MHP50-700-14	50	700	73.96	5200	118.2	14	160	279	684
242		MHP50-750-15	50	750	73.82	5200	118.2	15	160	279	689
243		MHP50-800-16	50	800	73.9	5200	118.2	16	185	322.5	715
244		MHP50-850-17	50	850	73.87	5200	118.2	17	185	322.5	720
245		MHP50-900-18	50	900	73.63	5200	118.2	18	185	322.5	726
246		MHP50-950-19	50	950	73.86	5200	118.2	19	200	350	766
247	MHP60	MHP60-420-6	60	420	70.09	5200	136	6	110	191.8	602
248		MHP60-490-7	60	490	70.1	5200	136	7	132	230	628
249		MHP60-560-8	60	560	70.15	5200	136	8	160	279	649
250		MHP60-630-9	60	630	70.33	5200	136	9	185	322.5	675
251		MHP60-700-10	60	700	70.16	5200	136	10	200	350	716

标签：

上一篇：南元泵业MS浸入式多级离心泵参数，规格型号

下一篇：南元泵业HSP立式超高压多级离心泵，配永磁变频电机，跨时代之作

南元泵业MHP卧式多级超高压离心泵，标配永磁变频电机，高效节能，高压力

4001 077 588
