南元泵业HSP立式超高压多级离心泵，配永磁变频电机，跨时代之作

发布时间：2026-01-08人气：358


序号	组名	型号	额定流量 (m³/h)	额定扬程 (m)	额定效率 (%)	额定转速 (rpm)	叶轮外径	叶轮级数	出口口径	电机功率	额定电流	泵重量(kg)
1	HSP2	HSP2-320-17	2	320	46.1	5200	73	17	DN25	5.5	9.8	59
2		HSP2-340-18	2	340	46.6	5200	73	18	DN25	5.5	9.8	60
3		HSP2-360-19	2	360	46.2	5200	73	19	DN25	5.5	9.8	60
4		HSP2-375-20	2	375	46.3	5200	73	20	DN25	5.5	9.8	61
5		HSP2-395-21	2	395	47.1	5200	73	21	DN25	7.5	13.3	64
6		HSP2-415-22	2	415	46.4	5200	73	22	DN25	7.5	13.3	67
7		HSP2-435-23	2	435	46	5200	73	22	DN25	7.5	13.3	67
8		HSP2-455-24	2	455	46.3	5200	73	24	DN25	7.5	13.3	68
9		HSP2-475-25	2	475	46	5200	73	24	DN25	7.5	13.3	68
10		HSP2-495-26	2	495	46.7	5200	73	25	DN25	7.5	13.3	69
11		HSP2-515-27	2	515	45.9	5200	73	27	DN25	7.5	13.3	69
12		HSP2-535-28	2	535	46.2	5200	73	28	DN25	11	19.5	82
13		HSP2-550-29	2	550	46.7	5200	73	29	DN25	11	19.5	82
14		HSP2-565-30	2	565	46.1	5200	73	29	DN25	11	19.5	83
15		HSP2-585-31	2	585	47	5200	73	30	DN25	11	19.5	84
16		HSP2-600-32	2	600	46.4	5200	73	31	DN25	11	19.5	86
17		HSP2-620-33	2	620	45.7	5200	73	32	DN25	11	19.5	86
18		HSP2-640-34	2	640	46.3	5200	73	34	DN25	11	19.5	87
19		HSP2-660-35	2	660	46.1	5200	73	34	DN25	11	19.5	87
20		HSP2-680-36	2	680	46.4	5200	73	35	DN25	11	19.5	88
21		HSP2-695-37	2	695	46.6	5200	73	37	DN25	11	19.5	88
22		HSP2-715-38	2	715	46.5	5200	73	38	DN25	11	19.5	88
23		HSP2-735-39	2	735	46.4	5200	73	38	DN25	11	19.5	89
24		HSP2-755-40	2	755	46.7	5200	73	40	DN25	11	19.5	89
25		HSP2-770-41	2	770	46.5	5200	73	41	DN25	15	26.5	95
26		HSP2-790-42	2	790	46.2	5200	73	42	DN25	15	26.5	95
27	HSP3	HSP3-285-17	3	285	52.8	5200	73	17	DN25	5.5	9.8	59
28		HSP3-300-18	3	300	52.4	5200	73	18	DN25	5.5	9.8	60
29		HSP3-320-19	3	320	52.6	5200	73	19	DN25	5.5	9.8	60
30		HSP3-340-20	3	340	52.5	5200	73	20	DN25	5.5	9.8	61
31		HSP3-355-21	3	355	52.7	5200	73	21	DN25	7.5	13.3	64
32		HSP3-370-22	3	370	52.5	5200	73	22	DN25	7.5	13.3	67
33		HSP3-385-23	3	385	52.4	5200	73	23	DN25	7.5	13.3	67
34		HSP3-400-24	3	400	52.6	5200	73	24	DN25	7.5	13.3	68
35		HSP3-420-25	3	420	52.6	5200	73	25	DN25	7.5	13.3	68
36		HSP3-440-26	3	440	52.5	5200	73	26	DN25	7.5	13.3	69
37		HSP3-460-27	3	460	52.4	5200	73	27	DN25	7.5	13.3	69
38		HSP3-475-28	3	475	52.7	5200	73	28	DN25	11	19.5	82
39		HSP3-490-29	3	490	52.7	5200	73	29	DN25	11	19.5	82
40		HSP3-505-30	3	505	52.6	5200	73	30	DN25	11	19.5	83
41		HSP3-520-31	3	520	53	5200	73	31	DN25	11	19.5	84
42		HSP3-535-32	3	535	52.4	5200	73	32	DN25	11	19.5	86
43		HSP3-555-33	3	555	52.9	5200	73	33	DN25	11	19.5	86
44		HSP3-570-34	3	570	53.3	5200	73	34	DN25	11	19.5	87
45		HSP3-590-35	3	590	52.6	5200	73	35	DN25	11	19.5	87
46		HSP3-605-36	3	605	52.6	5200	73	36	DN25	11	19.5	88
47		HSP3-620-37	3	620	52.8	5200	73	37	DN25	11	19.5	88
48		HSP3-640-38	3	640	53.2	5200	73	38	DN25	11	19.5	88
49		HSP3-655-39	3	655	53.1	5200	73	39	DN25	11	19.5	89
50		HSP3-670-40	3	670	52.8	5200	73	40	DN25	11	19.5	89
51		HSP3-690-41	3	690	52.3	5200	73	41	DN25	15	26.5	95
52		HSP3-705-42	3	705	52.6	5200	73	42	DN25	15	26.5	95
53	HSP4	HSP4-330-18	4	330	61.1	5200	73	18	DN32	7.5	13.3	64
54		HSP4-350-19	4	350	61	5200	73	19	DN32	7.5	13.3	64
55		HSP4-365-20	4	365	61.1	5200	73	20	DN32	11	19.5	77
56		HSP4-385-21	4	385	61.5	5200	73	21	DN32	11	19.5	78
57		HSP4-400-22	4	400	61.4	5200	73	22	DN32	11	19.5	81
58		HSP4-420-23	4	420	61.3	5200	73	23	DN32	11	19.5	81
59		HSP4-440-24	4	440	61.4	5200	73	24	DN32	11	19.5	81
60		HSP4-460-25	4	460	61.5	5200	73	25	DN32	11	19.5	82
61		HSP4-475-26	4	475	61.2	5200	73	26	DN32	11	19.5	82
62		HSP4-495-27	4	495	61.3	5200	73	27	DN32	11	19.5	83
63		HSP4-510-28	4	510	61.1	5200	73	28	DN32	11	19.5	83
64		HSP4-530-29	4	530	61.7	5200	73	29	DN32	15	26.5	88
65		HSP4-545-30	4	545	61.2	5200	73	30	DN32	15	26.5	89
66		HSP4-565-31	4	565	61	5200	73	31	DN32	15	26.5	89
67		HSP4-585-32	4	585	61.3	5200	73	32	DN32	15	26.5	90
68		HSP4-605-33	4	605	61.3	5200	73	33	DN32	15	26.5	91
69		HSP4-620-34	4	620	60.8	5200	73	34	DN32	15	26.5	93
70		HSP4-640-35	4	640	61.2	5200	73	35	DN32	15	26.5	93
71		HSP4-660-36	4	660	61.2	5200	73	36	DN32	15	26.5	94
72		HSP4-680-37	4	680	61.2	5200	73	37	DN32	15	26.5	94
73		HSP4-700-38	4	700	61.5	5200	73	38	DN32	15	26.5	95
74	HSP5	HSP5-305-18	5	305	62.2	5200	73	18	DN32	7.5	13.3	64
75		HSP5-320-19	5	320	62.4	5200	73	19	DN32	7.5	13.3	64
76		HSP5-340-20	5	340	62.2	5200	73	20	DN32	11	19.5	77
77		HSP5-355-21	5	355	61.9	5200	73	21	DN32	11	19.5	78
78		HSP5-370-22	5	370	62.1	5200	73	22	DN32	11	19.5	81
79		HSP5-390-23	5	390	62.8	5200	73	23	DN32	11	19.5	81
80		HSP5-405-24	5	405	62.5	5200	73	24	DN32	11	19.5	81
81		HSP5-425-25	5	425	62	5200	73	25	DN32	11	19.5	82
82		HSP5-440-26	5	440	62.6	5200	73	26	DN32	11	19.5	82
83		HSP5-455-27	5	455	62.3	5200	73	27	DN32	11	19.5	83
84		HSP5-470-28	5	470	62.1	5200	73	28	DN32	11	19.5	83
85		HSP5-490-29	5	490	62.7	5200	73	29	DN32	15	26.5	88
86		HSP5-510-30	5	510	62.2	5200	73	30	DN32	15	26.5	89
87		HSP5-525-31	5	525	62.6	5200	73	31	DN32	15	26.5	89
88		HSP5-540-32	5	540	62.4	5200	73	32	DN32	15	26.5	90
89		HSP5-560-33	5	560	62.3	5200	73	33	DN32	15	26.5	91
90		HSP5-575-34	5	575	62.3	5200	73	34	DN32	15	26.5	93
91		HSP5-590-35	5	590	62.4	5200	73	35	DN32	15	26.5	93
92		HSP5-610-36	5	610	61.8	5200	73	36	DN32	15	26.5	94
93		HSP5-630-37	5	630	62.7	5200	73	37	DN32	15	26.5	94
94		HSP5-645-38	5	645	62.1	5200	73	38	DN32	15	26.5	95
95	HSP8	HSP8-320-18	8	320	66.1	5200	73	18	DN40	15	26.5	85
96		HSP8-340-19	8	340	66.4	5200	73	19	DN40	15	26.5	86
97		HSP8-360-20	8	360	66.8	5200	73	20	DN40	15	26.5	86
98		HSP8-380-21	8	380	65.9	5200	73	21	DN40	15	26.5	87
99		HSP8-400-22	8	400	66	5200	73	22	DN40	18.5	32.6	103
100		HSP8-415-23	8	415	65.6	5200	73	23	DN40	18.5	32.6	103
101		HSP8-435-24	8	435	66.4	5200	73	24	DN40	18.5	32.6	104
102		HSP8-455-25	8	455	65.8	5200	73	25	DN40	18.5	32.6	104
103		HSP8-470-26	8	470	65.7	5200	73	26	DN40	22	38.7	110
104		HSP8-485-27	8	485	66.2	5200	73	27	DN40	22	38.7	111
105		HSP8-505-28	8	505	65.7	5200	73	28	DN40	22	38.7	111
106		HSP8-520-29	8	520	66.2	5200	73	29	DN40	22	38.7	112
107		HSP8-540-30	8	540	65.9	5200	73	30	DN40	22	38.7	112
108		HSP8-560-31	8	560	65.8	5200	73	31	DN40	22	38.7	113
109		HSP8-580-32	8	580	65.8	5200	73	32	DN40	30	52.6	178
110		HSP8-600-33	8	600	65.5	5200	73	33	DN40	30	52.6	180
111		HSP8-615-34	8	615	65.7	5200	73	34	DN40	30	52.6	182
112		HSP8-630-35	8	630	66	5200	73	35	DN40	30	52.6	183
113		HSP8-650-36	8	650	65.9	5200	73	36	DN40	30	52.6	184
114		HSP8-670-37	8	670	65.9	5200	73	37	DN40	30	52.6	184
115		HSP8-690-38	8	690	66.2	5200	73	38	DN40	30	52.6	185
116		HSP8-705-39	8	705	65.9	5200	73	39	DN40	30	52.6	186
117	HSP10	HSP10-320-20	10	320	64.36	5200	73	20	DN40	15	26.5	86
118		HSP10-340-21	10	340	67	5200	73	21	DN40	15	26.5	87
119		HSP10-355-22	10	355	66.7	5200	73	22	DN40	18.5	32.6	103
120		HSP10-370-23	10	370	67.3	5200	73	23	DN40	18.5	32.6	103
121		HSP10-385-24	10	385	67.4	5200	73	24	DN40	18.5	32.6	104
122		HSP10-405-25	10	405	66.4	5200	73	25	DN40	18.5	32.6	104
123		HSP10-420-26	10	420	66.1	5200	73	26	DN40	22	38.7	110
124		HSP10-435-27	10	435	64.36	5200	73	27	DN40	22	38.7	111
125		HSP10-450-28	10	450	64.9	5200	73	28	DN40	22	38.7	111
126		HSP10-470-29	10	470	66.6	5200	73	29	DN40	22	38.7	112
127		HSP10-485-30	10	485	66.5	5200	73	30	DN40	22	38.7	112
128		HSP10-500-31	10	500	66.4	5200	73	31	DN40	22	38.7	113
129		HSP10-515-32	10	515	66.8	5200	73	32	DN40	30	52.6	178
130		HSP10-530-33	10	530	66.5	5200	73	33	DN40	30	52.6	180
131		HSP10-550-34	10	550	67	5200	73	34	DN40	30	52.6	182
132		HSP10-565-35	10	565	66.8	5200	73	35	DN40	30	52.6	183
133		HSP10-580-36	10	580	67.2	5200	73	36	DN40	30	52.6	184
134		HSP10-600-37	10	600	66.9	5200	73	37	DN40	30	52.6	184
135		HSP10-615-38	10	615	67.4	5200	73	38	DN40	30	52.6	185
136		HSP10-630-39	10	630	66.9	5200	73	39	DN40	30	52.6	186
137	HSP12	HSP12-320-10	12	320	65.2	5200	96.3	10	DN50	22	38.7	109
138		HSP12-350-11	12	350	65.2	5200	96.3	11	DN50	22	38.7	110
139		HSP12-380-12	12	380	65.4	5200	96.3	12	DN50	22	38.7	111
140		HSP12-415-13	12	415	65.2	5200	96.3	13	DN50	30	52.6	182
141		HSP12-450-14	12	450	65.4	5200	96.3	14	DN50	30	52.6	183
142		HSP12-480-15	12	480	65	5200	96.3	15	DN50	30	52.6	184
143		HSP12-510-16	12	510	65	5200	96.3	16	DN50	30	52.6	185
144		HSP12-545-17	12	545	64.9	5200	96.3	17	DN50	37	64.9	197
145		HSP12-580-18	12	580	65.2	5200	96.3	18	DN50	37	64.9	199
146		HSP12-610-19	12	610	65	5200	96.3	19	DN50	37	64.9	203
147		HSP12-640-20	12	640	65.4	5200	96.3	20	DN50	45	78.7	246
148		HSP12-670-21	12	670	64.9	5200	96.3	21	DN50	45	78.7	247
149		HSP12-700-22	12	700	65.3	5200	96.3	22	DN50	45	78.7	248
150	HSP15	HSP15-310-11	15	310	68.6	5200	92.3	11	DN50	22	38.7	110
151		HSP15-335-12	15	335	69.9	5200	92.3	12	DN50	22	38.7	111
152		HSP15-360-13	15	360	69.46	5200	92.3	13	DN50	30	52.6	179
153		HSP15-390-14	15	390	69.01	5200	92.3	14	DN50	30	52.6	183
154		HSP15-415-15	15	415	68.84	5200	92.3	15	DN50	30	52.6	184
155		HSP15-445-16	15	445	68.94	5200	92.3	16	DN50	30	52.6	185
156		HSP15-470-17	15	470	68.83	5200	92.3	17	DN50	37	64.9	197
157		HSP15-500-18	15	500	69.09	5200	92.3	18	DN50	37	64.9	199
158		HSP15-520-19	15	520	69.06	5200	92.3	19	DN50	37	64.9	200
159		HSP15-550-20	15	550	69.04	5200	92.3	20	DN50	37	64.9	201
160		HSP15-580-21	15	580	69.27	5200	92.3	21	DN50	45	78.7	244
161		HSP15-610-22	15	610	68.91	5200	92.3	22	DN50	45	78.7	248
162		HSP15-640-23	15	640	69.4	5200	92.3	23	DN50	45	78.7	249
163		HSP15-670-24	15	670	69.13	5200	92.3	24	DN50	45	78.7	250
164		HSP15-700-25	15	700	69.04	5200	92.3	25	DN50	45	78.7	247
165	HSP16	HSP16-300-11	16	300	70.84	5200	92.3	11	DN50	22	38.7	110
166		HSP16-330-12	16	330	70.85	5200	92.3	12	DN50	22	38.7	111
167		HSP16-350-13	16	350	70.57	5200	92.3	13	DN50	30	52.6	179
168		HSP16-380-14	16	380	70.34	5200	92.3	14	DN50	30	52.6	183
169		HSP16-410-15	16	410	70.1	5200	92.3	15	DN50	30	52.6	184
170		HSP16-430-16	16	430	70.77	5200	92.3	16	DN50	30	52.6	185
171		HSP16-455-17	16	455	70.32	5200	92.3	17	DN50	37	64.9	197
172		HSP16-480-18	16	480	70.47	5200	92.3	18	DN50	37	64.9	199
173		HSP16-510-19	16	510	70.17	5200	92.3	19	DN50	37	64.9	200
174		HSP16-535-20	16	535	69.89	5200	92.3	20	DN50	37	64.9	201
175		HSP16-560-21	16	560	70.84	5200	92.3	21	DN50	45	78.7	244
176		HSP16-590-22	16	590	70.33	5200	92.3	22	DN50	45	78.7	248
177		HSP16-620-23	16	620	70.11	5200	92.3	23	DN50	45	78.7	249
178		HSP16-650-24	16	650	70.64	5200	92.3	24	DN50	45	78.7	250
179		HSP16-680-25	16	680	70.36	5200	92.3	25	DN50	45	78.7	252
180		HSP16-700-26	16	700	69.85	5200	92.3	26	DN50	55	96	271
181	HSP20	HSP20-250-11	20	250	66.99	5200	92.3	11	DN50	22	38.7	101
182		HSP20-280-12	20	280	66.86	5200	92.3	12	DN50	22	38.7	111
183		HSP20-300-13	20	300	66.22	5200	92.3	13	DN50	30	52.6	179
184		HSP20-320-14	20	320	66.35	5200	92.3	14	DN50	30	52.6	183
185		HSP20-350-15	20	350	66.23	5200	92.3	15	DN50	30	52.6	184
186		HSP20-375-16	20	375	66.47	5200	92.3	16	DN50	30	52.6	185
187		HSP20-400-17	20	400	67.29	5200	92.3	17	DN50	37	64.9	197
188		HSP20-425-18	20	425	66.11	5200	92.3	18	DN50	37	64.9	199
189		HSP20-445-19	20	445	66.58	5200	92.3	19	DN50	37	64.9	200
190		HSP20-470-20	20	470	66.42	5200	92.3	20	DN50	37	64.9	201
191		HSP20-495-21	20	495	66.8	5200	92.3	21	DN50	45	78.7	244
192		HSP20-520-22	20	520	66.82	5200	92.3	22	DN50	45	78.7	247
193		HSP20-540-23	20	540	66.04	5200	92.3	23	DN50	45	78.7	248
194		HSP20-570-24	20	570	66.72	5200	92.3	24	DN50	45	78.7	249
195		HSP20-600-25	20	600	66.86	5200	92.3	25	DN50	45	78.7	251
196		HSP20-630-26	20	630	66.14	5200	92.3	26	DN50	55	96	270
197		HSP20-650-27	20	650	66.83	5200	92.3	27	DN50	55	96	271
198		HSP20-680-28	20	680	66.88	5200	92.3	28	DN50	55	96	272
199	HSP25	HSP25-340-9	25	340	64.99	5200	104.4	9	DN50	45	78.7	229
200		HSP25-375-10	25	375	65.26	5200	104.4	10	DN50	55	96	251
201		HSP25-415-11	25	415	65.08	5200	104.4	11	DN50	55	96	253
202		HSP25-455-12	25	455	65.2	5200	104.4	12	DN50	75	131.2	289
203		HSP25-490-13	25	490	64.9	5200	104.4	13	DN50	75	131.2	292
204		HSP25-530-14	25	530	65.16	5200	104.4	14	DN50	75	131.2	295
205		HSP25-570-15	25	570	65.03	5200	104.4	15	DN50	75	131.2	300
206		HSP25-610-16	25	610	65.26	5200	104.4	16	DN50	90	157.1	326
207		HSP25-650-17	25	650	65.31	5200	104.4	17	DN50	90	157.1	328
208		HSP25-690-18	25	690	64.61	5200	104.4	18	DN50	90	157.1	330
209	HSP30	HSP30-310-9	30	310	67.85	5200	104.4	9	DN50	45	78.7	224
210		HSP30-345-10	30	345	67.31	5200	104.4	10	DN50	55	96	246
211		HSP30-380-11	30	380	67.23	5200	104.4	11	DN50	55	96	248
212		HSP30-415-12	30	415	67.5	5200	104.4	12	DN50	75	131.2	284
213		HSP30-450-13	30	450	67.09	5200	104.4	13	DN50	75	131.2	287
214		HSP30-490-14	30	490	68.17	5200	104.4	14	DN50	75	131.2	290
215		HSP30-525-15	30	525	67.59	5200	104.4	15	DN50	75	131.2	294
216		HSP30-560-16	30	560	67.59	5200	104.4	16	DN50	90	157.1	321
217		HSP30-600-17	30	600	67.38	5200	104.4	17	DN50	90	157.1	323
218		HSP30-640-18	30	640	67.05	5200	104.4	18	DN50	90	157.1	325

标签：

上一篇：南元泵业MHP卧式多级超高压离心泵，标配永磁变频电机，高效节能，高压力

下一篇：南元泵业MSP系列浸入式超高压多级离心泵，高压机床行业的首选，配永磁变频电机

南元泵业HSP立式超高压多级离心泵，配永磁变频电机，跨时代之作

4001 077 588
