南元泵业MSP系列浸入式超高压多级离心泵，高压机床行业的首选，配永磁变频电机

发布时间：2026-01-08人气：323


序号	组名	型号	额定流量 (m³/h)	额定扬程 (m)	额定效率 (%)	额定转速 (rpm)	叶轮外径	叶轮级数
1	MSP2	MSP2-210-13/13	2	210	45.9	5000	73	13
2		MSP2-225-14/14	2	225	45.9	5000	73	14
3		MSP2-245-15/15	2	245	45.9	5000	73	15
4		MSP2-260-16/16	2	260	45.9	5000	73	16
5		MSP2-275-17/17	2	275	45.9	5000	73	17
6		MSP2-290-18/18	2	290	45.9	5000	73	18
7		MSP2-305-19/19	2	305	45.9	5000	73	19
8		MSP2-325-20/20	2	325	45.9	5000	73	20
9		MSP2-340-21/21	2	340	45.9	5000	73	21
10		MSP2-355-22/22	2	355	45.9	5000	73	22
11		MSP2-370-23/23	2	370	45.9	5000	73	23
12		MSP2-385-24/24	2	385	45.9	5000	73	24
13		MSP2-405-25/25	2	405	45.9	5000	73	25
14		MSP2-420-26/26	2	420	45.9	5000	73	26
15		MSP2-435-27/27	2	435	45.9	5000	73	27
16		MSP2-455-28/28	2	455	45.9	5000	73	28
17		MSP2-470-29/29	2	475	45.9	5000	73	29
18		MSP2-485-30/30	2	485	45.9	5000	73	30
19		MSP2-500-31/31	2	500	45.9	5000	73	31
20		MSP2-520-32/32	2	520	45.9	5000	73	32
21		MSP2-535-33/33	2	535	45.9	5000	73	33
22		MSP2-550-34/34	2	550	45.9	5000	73	34
23		MSP2-565-35/35	2	565	45.9	5000	73	35
24		MSP2-580-36/36	2	580	45.9	5000	73	36
25	MSP3	MSP3-275-18/18	3	275	54.1	5000	73	18
26		MSP3-290-19/19	3	290	54.1	5000	73	19
27		MSP3-305-20/20	3	305	54.1	5000	73	20
28		MSP3-320-21/21	3	320	54.1	5000	73	21
29		MSP3-335-22/22	3	335	54.1	5000	73	22
30		MSP3-350-23/23	3	350	54.1	5000	73	23
31		MSP3-360-24/24	3	360	54.1	5000	73	24
32		MSP3-375-25/25	3	375	54.1	5000	73	25
33		MSP3-390-26/26	3	390	54.1	5000	73	26
34		MSP3-405-27/27	3	405	54.1	5000	73	27
35		MSP3-420-28/28	3	420	54.1	5000	73	28
36		MSP3-435-29/29	3	435	54.1	5000	73	29
37		MSP3-450-30/30	3	450	54.1	5000	73	30
38		MSP3-465-31/31	3	465	54.1	5000	73	31
39		MSP3-480-32/32	3	480	54.1	5000	73	32
40		MSP3-495-33/33	3	495	54.1	5000	73	33
41		MSP3-510-34/34	3	510	54.1	5000	73	34
42		MSP3-530-35/35	3	530	54.1	5000	73	35
43		MSP3-545-36/36	3	545	54.1	5000	73	36
44	MSP4	MSP4-185-11/11	4	185	59.2	5000	73	11
45		MSP4-200-12/12	4	200	59.2	5000	73	12
46		MSP4-215-13/13	4	215	59.2	5000	73	13
47		MSP4-235-14/14	4	235	59.2	5000	73	14
48		MSP4-250-15/15	4	250	59.2	5000	73	15
49		MSP4-265-16/16	4	265	59.2	5000	73	16
50		MSP4-285-17/17	4	285	59.2	5000	73	17
51		MSP4-300-18/18	4	300	59.2	5000	73	18
52		MSP4-315-19/19	4	315	59.2	5000	73	19
53		MSP4-335-20/20	4	335	59.2	5000	73	20
54		MSP4-350-21/21	4	350	59.2	5000	73	21
55		MSP4-370-22/22	4	370	59.2	5000	73	22
56		MSP4-385-23/23	4	385	59.2	5000	73	23
57		MSP4-400-24/24	4	400	59.2	5000	73	24
58		MSP4-420-25/25	4	420	59.2	5000	73	25
59		MSP4-435-26/26	4	435	59.2	5000	73	26
60		MSP4-450-27/27	4	450	59.2	5000	73	27
61		MSP4-470-28/28	4	470	59.2	5000	73	28
62		MSP4-485-29/29	4	485	59.2	5000	73	29
63		MSP4-500-30/30	4	500	59.2	5000	73	30
64		MSP4-520-31/31	4	520	59.2	5000	73	31
65		MSP4-535-32/32	4	535	59.2	5000	73	32
66		MSP4-550-33/33	4	550	59.2	5000	73	33
67		MSP4-570-34/34	4	570	59.2	5000	73	34
68		MSP4-585-35/35	4	585	59.2	5000	73	35
69		MSP4-600-36/36	4	600	59.2	5000	73	36
70	MSP5	MSP5-290-19/19	5	290	62.1	5000	73	19
71		MSP5-305-20/20	5	305	62.1	5000	73	20
72		MSP5-320-21/21	5	320	62.1	5000	73	21
73		MSP5-335-22/22	5	335	62.1	5000	73	22
74		MSP5-350-23/23	5	350	62.1	5000	73	23
75		MSP5-365-24/24	5	365	62.1	5000	73	24
76		MSP5-380-25/25	5	380	62.1	5000	73	25
77		MSP5-400-26/26	5	400	62.1	5000	73	26
78		MSP5-415-27/27	5	415	62.1	5000	73	27
79		MSP5-430-28/28	5	530	62.1	5000	73	28
80		MSP5-445-29/29	5	445	62.1	5000	73	29
81		MSP5-460-30/30	5	460	62.1	5000	73	30
82		MSP5-475-31/31	5	475	62.1	5000	73	31
83		MSP5-490-32/32	5	490	62.1	5000	73	32
84		MSP5-505-33/33	5	505	62.1	5000	73	33
85		MSP5-520-34/34	5	520	62.1	5000	73	34
86		MSP5-535-35/35	5	535	62.1	5000	73	35
87		MSP5-550-36/36	5	550	62.1	5000	73	36
88	MSP8	MSP8-270-17/17	8	270	59.3	5000	73	17
89		MSP8-295-18/18	8	295	59.3	5000	73	18
90		MSP8-310-19/19	8	310	59.3	5000	73	19
91		MSP8-325-20/20	8	325	59.3	5000	73	20
92		MSP8-345-21/21	8	345	59.3	5000	73	21
93		MSP8-360-22/22	8	360	59.3	5000	73	22
94		MSP8-375-23/23	8	375	59.3	5000	73	23
95		MSP8-395-24/24	8	395	59.3	5000	73	24
96		MSP8-410-25/25	8	410	59.3	5000	73	25
97		MSP8-425-26/26	8	425	59.3	5000	73	26
98		MSP8-445-27/27	8	445	59.3	5000	73	27
99		MSP8-460-28/28	8	460	59.3	5000	73	28
100		MSP8-475-29/29	8	475	59.3	5000	73	29
101		MSP8-490-30/30	8	490	59.3	5000	73	30
102		MSP8-510-31/31	8	510	59.3	5000	73	31
103		MSP8-525-32/32	8	525	59.3	5000	73	32
104		MSP8-540-33/33	8	540	59.3	5000	73	33
105		MSP8-560-34/34	8	560	59.3	5000	73	34
106		MSP8-575-35/35	8	575	59.3	5000	73	35
107		MSP8-590-36/36	8	590	59.3	5000	73	36
108	MSP10	MSP10-275-19/19	10	275	59.6	5000	73	19
109		MSP10-290-20/20	10	590	59.6	5000	73	20
110		MSP10-300-21/21	10	300	59.6	5000	73	21
111		MSP10-315-22/22	10	315	59.6	5000	73	22
112		MSP10-330-23/23	10	330	59.6	5000	73	23
113		MSP10-345-24/24	10	345	59.6	5000	73	24
114		MSP10-360-25/25	10	360	59.6	5000	73	25
115		MSP10-375-26/26	10	375	59.6	5000	73	26
116		MSP10-390-27/27	10	390	59.6	5000	73	27
117		MSP10-405-28/28	10	405	59.6	5000	73	28
118		MSP10-420-29/29	10	420	59.6	5000	73	29
119		MSP10-435-30/30	10	435	59.6	5000	73	30
120		MSP10-450-31/31	10	450	59.6	5000	73	31
121		MSP10-460-32/32	10	460	59.6	5000	73	32
122		MSP10-475-33/33	10	475	59.6	5000	73	33
123		MSP10-490-34/34	10	490	59.6	5000	73	34
124		MSP10-505-35/35	10	505	59.6	5000	73	35
125		MSP10-520-36/36	10	520	59.6	5000	73	36
