南元泵业DS系列卧式端吸离心泵参数表，型谱宽，已选型，高效节能

发布时间：2026-01-08人气：293


序号	组名	型号	额定流量 (m³/h)	额定扬程 (m)	额定效率 (%)	额定转速 (rpm)
1	DS50-32	DS50-32-125.1C-0.75/2	12	11	57.1	2900
2		DS50-32-125.1B-1.1/2	14	14	62.5	2900
3		DS50-32-125.1A-1.5/2	16	18	66.9	2900
4		DS50-32-125.1-2.2/2	16	25	66.8	2900
5		DS50-32-125C-1.1/2	20	12	66.4	2900
6		DS50-32-125B-1.5/2	22	14	65.5	2900
7		DS50-32-125A-2.2/2	25	18	67	2900
8		DS50-32-125-3/2	28	20	64.3	2900
9		DS50-32-160C-2.2/2	22	22	63.9	2900
10		DS50-32-160B-3/2	22	26	63	2900
11		DS50-32-160A-4/2	25	32	65.9	2900
12		DS50-32-160-5.5/2	28	40	66.1	2900
13		DS50-32-200C-4/2	18	31	41.4	2900
14		DS50-32-200B-5.5/2	20	40	43.4	2900
15		DS50-32-200A-7.5/2	25	48	48.5	2900
16		DS50-32-200-11/2	22	61	45.4	2950
17		DS50-32-250C-5.5/2	16	39	30.8	2900
18		DS50-32-250B-7.5/2	20	49.5	40.8	2900
19		DS50-32-250A-11/2	22	67	42.1	2950
20		DS50-32-250-15/2	24	91	44.5	2950
21		DS50-32-125.1B-0.25/4	10	4.2	69.2	1450
22		DS50-32-125.1A-0.25/4	10	6	69.3	1450
23		DS50-32-125.1-0.37/4	11	6.5	70.6	1450
24		DS50-32-125B-0.25/4	8	3.7	51.6	1450
25		DS50-32-125A-0.25/4	11	4.5	60.7	1450
26		DS50-32-125-0.37/4	13	5	61.5	1450
27		DS50-32-160C-0.25/4	10	5.4	58.4	1450
28		DS50-32-160B-0.37/4	12	7	63	1450
29		DS50-32-160A-0.55/4	14	8.3	65.1	1450
30		DS50-32-160-0.75/4	14	10	65	1450
31		DS50-32-200C-0.55/4	10	8.9	42.8	1450
32		DS50-32-200B-0.75/4	12	10	47	1450
33		DS50-32-200A-1.1/4	12	13	46	1450
34		DS50-32-200-1.5/4	16	15	46	1450
35		DS50-32-250C-0.75/4	10	10.7	40.1	1450
36		DS50-32-250B-1.1/4	10	12.5	38.3	1450
37		DS50-32-250A-1.5/4	10	18	37.3	1450
38		DS50-32-250-2.2/4	12	22.8	41.8	1450
39	DS65-40	DS65-40-200C-5.5/2	35	30	56.1	2900
40		DS65-40-200B-7.5/2	40	36	58.2	2900
41		DS65-40-200A-11/2	50	47	61.9	2950
42		DS65-40-200-15/2	50	60	62.3	2950
43		DS65-40-250D-11/2	40	43	49.1	2950
44		DS65-40-250C-15/2	50	51	51.5	2950
45		DS65-40-250B-18.5/2	50	64	52	2950
46		DS65-40-250A-22/2	50	76	54.4	2950
47		DS65-40-250-30/2	60	93	60.6	2950
48		DS65-40-315D-22/2	30	90	44.7	2950
49		DS65-40-315C-30/2	40	106	43.5	2950
50		DS65-40-315B-37/2	40	116	42.1	2950
51		DS65-40-315A-37/2	40	125	42.1	2950
52		DS65-40-315-45/2	40	148	41.6	2950
53		DS65-40-200C-0.75/4	18	7.7	54.2	1450
54		DS65-40-200B-1.1/4	20	11	55.9	1450
55		DS65-40-200A-1.5/4	22	13.5	58.6	1450
56		DS65-40-200-2.2/4	26	15	59.9	1450
57		DS65-40-250B-1.5/4	22	13	54.2	1450
58		DS65-40-250A-2.2/4	25	17.5	57.8	1450
59		DS65-40-250-3/4	25	22	57.9	1450
60		DS65-40-315C-3/4	20	21	42.9	1450
61		DS65-40-315B-4/4	20	27	42.1	1450
62		DS65-40-315A-5.5/4	22	34	43.8	1450
63		DS65-40-315-7.5/4	25	38	46.6	1450
64	DS65-50	DS65-50-125D-1.5/2	32	10	71.4	2900
65		DS65-50-125C-2.2/2	35	14	73.5	2900
66		DS65-50-125B-3/2	40	17.5	74.3	2900
67		DS65-50-125A-4/2	45	21.5	73.5	2900
68		DS65-50-125-5.5/2	50	21.5	74.9	2900
69		DS65-50-160C-4/2	35	25	69.3	2900
70		DS65-50-160B-5.5/2	45	29	71.6	2900
71		DS65-50-160A-7.5/2	45	37	68	2900
72		DS65-50-160-11/2	50	41	69.3	2950
73		DS65-50-125B-0.25/4	18	3.3	59.5	1450
74		DS65-50-125A-0.37/4	20	4.5	68	1450
75		DS65-50-125-0.55/4	22	5.5	68.9	1450
76		DS65-50-160C-0.37/4	15	4.9	53.6	1450
77		DS65-50-160B-0.55/4	18	6	57.1	1450
78		DS65-50-160A-0.75/4	22	7.4	61.2	1450
79		DS65-50-160-1.1/4	24	10	66.3	1450
80	DS80-50	DS80-50-200C-11/2	60	40	73	2950
81		DS80-50-200B-15/2	60	55	75.4	2950
82		DS80-50-200A-18.5/2	60	60	75.4	2950
83		DS80-50-200-22/2	60	70	75.5	2950
84		DS80-50-250D-15/2	60	51	62	2950
85		DS80-50-250C-18.5/2	65	59	63.8	2950
86		DS80-50-250B-22/2	70	66	64	2950
87		DS80-50-250A-30/2	80	80	67	2950
88		DS80-50-250-37/2	90	90	66.7	2950
89		DS80-50-315D-30/2	55	81	45.8	2950
90		DS80-50-315C-37/2	60	94	48	2950
91		DS80-50-315B-45/2	60	112	48.4	2950
92		DS80-50-315A-55/2	65	136	51.3	2950
93		DS80-50-315-75/2	80	160	55.5	2950
94		DS80-50-200C-1.1/4	30	9	74.6	1450
95		DS80-50-200B-1.5/4	30	12	75.2	1450
96		DS80-50-200A-2.2/4	40	13	79.1	1450
97		DS80-50-200-3/4	40	15	79.3	1450
98		DS80-50-250B-2.2/4	30	14	59.2	1450
99		DS80-50-250A-3/4	40	16	65.8	1450
100		DS80-50-250-4/4	45	20	66.1	1450
101		DS80-50-315C-4/4	28	22	45.2	1450
102		DS80-50-315B-5.5/4	30	28	46	1450
103		DS80-50-315A-7.5/4	35	35	49.7	1450
104		DS80-50-315-11/4	50	41	57.9	1480
105	DS80-65	DS80-65-125C-3/2	45	14	68.9	2900
106		DS80-65-125B-4/2	55	16.5	72.2	2900
107		DS80-65-125A-5.5/2	65	20	72.7	2900
108		DS80-65-125-7.5/2	70	24	71.8	2900
109		DS80-65-160C-5.5/2	60	20	71.6	2900
110		DS80-65-160B-7.5/2	70	25	64.5	2900
111		DS80-65-160A-11/2	75	33	75.3	2950
112		DS80-65-160-15/2	85	38	76.2	2950
113		DS80-65-125B-0.55/4	30	4.2	70.4	1450
114		DS80-65-125A-0.75/4	30	5	69.5	1450
115		DS80-65-125-1.1/4	35	5.8	68.3	1450
116		DS80-65-160D-0.55/4	30	4	63.9	1450
117		DS80-65-160C-0.75/4	30	5	66.4	1450
118		DS80-65-160B-1.1/4	35	6.7	69.3	1450
119		DS80-65-160A-1.5/4	45	8.5	73.7	1450
120		DS80-65-160-2.2/4	45	8.8	73.5	1450
121	DS100-65	DS100-65-200E-11/2	100	27	67.3	2950
122		DS100-65-200D-15/2	100	33	75.2	2950
123		DS100-65-200C-18.5/2	120	35	77.3	2950
124		DS100-65-200B-22/2	120	63	78	2950
125		DS100-65-200A-30/2	120	53	80.2	2950
126		DS100-65-200-37/2	120	65	82.3	2950
127		DS100-65-250C-30/2	110	62	72.6	2950
128		DS100-65-250B-37/2	110	73	72.4	2950
129		DS100-65-250A-45/2	110	85	71.7	2950
130		DS100-65-250-55/2	110	102	70.1	2950
131		DS100-65-315C-55/2	120	90	62.2	2950
132		DS100-65-315B-75/2	140	110	65.4	2950
133		DS100-65-315A-90/2	150	123	65.5	2950
134		DS100-65-315-110/2	150	135	65.5	2950
135		DS100-65-200C-1.5/4	45	8.5	76.7	1450
136		DS100-65-200B-2.2/4	50	11	78.5	1450
137		DS100-65-200A-3/4	60	13	82.7	1450
138		DS100-65-200-4/4	60	15	83.3	1450
139		DS100-65-250C-3/4	50	13.5	67	1450
140		DS100-65-250B-4/4	60	17	70.9	1450
141		DS100-65-250A-5.5/4	60	20.5	70	1450
142		DS100-65-250-7.5/4	70	23	72.9	1450
143		DS100-65-315C-5.5/4	60	18	60.1	1450
144		DS100-65-315B-7.5/4	70	21	61.1	1450
145		DS100-65-315A-11/4	80	29	63.9	1480
146		DS100-65-315-15/4	90	32	65.7	1480
147	DS100-80	DS100-80-125C-4/2	70	14	70.4	2900
148		DS100-80-125B-5.5/2	90	15	76.1	2900
149		DS100-80-125A-7.5/2	100	18.5	76.9	2900
150		DS100-80-125-11/2	120	21.5	78.3	2950
151		DS100-80-160C-7.5/2	100	20	79.7	2900
152		DS100-80-160B-11/2	110	27	80.7	2950
153		DS100-80-160A-15/2	120	34	82.7	2950
154		DS100-80-160-18.5/2	120	37.5	82.1	2950
155		DS100-80-125B-0.75/4	50	4	78.6	1450
156		DS100-80-125-1.1/4	55	5.4	80	1450
157		DS100-80-160C-0.75/4	45	4.5	77.5	1450
158		DS100-80-160B-1.1/4	50	6	79.6	1450
159		DS100-80-160A-1.5/4	60	7	81	1450
160		DS100-80-160-2.2/4	65	9	80.9	1450
161	DS125-80	DS125-80-160C-11/2	150	20	77.4	2950
162		DS125-80-160B-15/2	160	25	78.9	2950
163		DS125-80-160A-18.5/2	180	26	80.2	2950
164		DS125-80-160-22/2	200	31	79.9	2950
165		DS125-80-200D-22/2	160	32	74	2950
166		DS125-80-200C-30/2	180	41	78.7	2950
167		DS125-80-200B-37/2	180	51	79.8	2950
168		DS125-80-200A-45/2	200	58	80.8	2950
169		DS125-80-200-55/2	220	58	82.3	2950
170		DS125-80-250C-45/2	180	61	77.2	2950
171		DS125-80-250B-55/2	200	70	78.5	2950
172		DS125-80-250A-75/2	200	90	78.8	2950
173		DS125-80-250-90/2	200	99	77.8	2950
174		DS125-80-315D-90/2	180	102	63.4	2950
175		DS125-80-315C-110/2	200	112	66.4	2950
176		DS125-80-315B-110/2	200	121	66.4	2950
177		DS125-80-315A-132/2	200	139	67.5	2950
178		DS125-80-315-160/2	200	154	67.5	2950
179		DS125-80-160B-1.5/4	75	4.5	73.3	1450
180		DS125-80-160A-2.2/4	80	6.8	78.9	1450
181		DS125-80-160-3/4	100	8	79.4	1450
182		DS125-80-200D-2.2/4	70	7	70.8	1450
183		DS125-80-200C-3/4	80	9	75.7	1450
184		DS125-80-200B-4/4	90	11.5	79.1	1450
185		DS125-80-200A-5.5/4	100	13.5	80.2	1450
186		DS125-80-200-7.5/4	100	15	81.9	1450
187		DS125-80-250B-5.5/4	90	15	74.3	1450
188		DS125-80-250A-7.5/4	100	19	76.4	1450
189		DS125-80-250-11/4	110	25	79.3	1480
190		DS125-80-315C-11/4	100	23.5	66.4	1480
191		DS125-80-315B-15/4	120	28	71.7	1480
192		DS125-80-315A-18.5/4	130	32.5	73.6	1480
193		DS125-80-315-22/4	140	37.5	75	1480
194		DS125-80-400D-18.5/4	100	36	57.7	1480
195		DS125-80-400C-22/4	110	40	60.3	1480
196		DS125-80-400B-30/4	130	48	65.4	1480
197		DS125-80-400A-37/4	140	56	65.6	1480
198		DS125-80-400-45/4	150	64	66	1480
199	DS125-100	DS125-100-200D-30/2	220	31	73.5	2950
200		DS125-100-200C-37/2	240	38	76.9	2950
201		DS125-100-200B-45/2	280	41	79.3	2950
202		DS125-100-200A-55/2	280	50	80	2950
203		DS125-100-200-75/2	280	62	81.3	2950
204		DS125-100-250D-55/2	240	51	74.6	2950
205		DS125-100-250C-75/2	240	69	73.3	2950
206		DS125-100-250B-90/2	240	80	70.2	2950
207		DS125-100-250A-110/2	260	94	74.4	2950
208		DS125-100-250-132/2	260	103	74.3	2950
209		DS125-100-315C-110/2	260	92	69.3	2950
210		DS125-100-315B-132/2	260	112	70.4	2950
211		DS125-100-315A-160/2	260	130	70.6	2950
212		DS125-100-315-200/2	260	149	70.4	2950
213		DS125-100-160B-2.2/4	100	5	75.4	1450
214		DS125-100-160A-3/4	110	7	80.3	1450
215		DS125-100-160-4/4	110	8	81.5	1450
216		DS125-100-200C-4/4	140	7.3	69.3	1450
217		DS125-100-200B-5.5/4	140	10	76	1450
218		DS125-100-200A-7.5/4	160	12	76.7	1450
219		DS125-100-200D-11/4	180	14	77.4	1480
220		DS125-100-250B-7.5/4	140	12	70.7	1450
221		DS125-100-250A-11/4	140	18	72.2	1480
222		DS125-100-250-15/4	160	23	73.5	1480
223		DS125-100-315C-15/4	150	24	75	1480
224		DS125-100-315B-18.5/4	160	27	74.1	1480
225		DS125-100-315A-22/4	180	30.5	75.4	1480
226		DS125-100-315-30/4	200	36	77.2	1480
227		DS125-100-400D-22/4	140	33	62.2	1480
228		DS125-100-400C-30/4	160	39	64.8	1480
229		DS125-100-400B-37/4	200	43	67.8	1480
230		DS125-100-400A-45/4	200	49	68.1	1480
231		DS125-100-400-55/4	220	55	67.5	1480
232	DS150-125	DS150-125-200C-5.5/4	180	7.8	71.5	1450
233		DS150-125-200B-7.5/4	180	10	75.6	1450
234		DS150-125-200A-11/4	240	12	78.3	1480
235		DS150-125-250D-11/4	240	12	75.8	1480
236		DS150-125-250C-15/4	260	14.5	78.5	1480
237		DS150-125-250B-18.5/4	300	16	78.9	1480
238		DS150-125-250A-22/4	300	20	81	1480
239		DS150-125-250-30/4	320	20	82.8	1480
240		DS150-125-315D-18.5/4	220	19	71.2	1480
241	DS150-125	DS150-125-315C-22/4	240	21	71.9	1480
242		DS150-125-315B-30/4	240	29	79.4	1480
243		DS150-125-315A-37/4	300	31	74.3	1480
244		DS150-125-315-45/4	300	34	75.2	1480
245		DS150-125-400D-37/4	220	37	71.6	1480
246		DS150-125-400C-45/4	240	42	71.7	1480
247		DS150-125-400B-55/4	300	44	74.8	1480
248		DS150-125-400A-75/4	320	58	74.7	1480
249		DS150-125-400-90/4	320	60	75	1480
250		DS150-125-500E-55/4	200	54	50.6	1480
251		DS150-125-500D-75/4	240	61	55.7	1480
252		DS150-125-500C-90/4	280	64	59.3	1480
253		DS150-125-500B-110/4	300	78	62.1	1480
254		DS150-125-500A-132/4	300	88	62.2	1480
255		DS150-125-500-160/4	300	102	64.5	1480
256	DS200-150	DS200-150-200B-7.5/4	220	8.5	64.1	1480
257		DS200-150-200A-11/4	250	10	68.7	1480
258		DS200-150-200-15/4	280	12	73.8	1480
259		DS200-150-250D-15/4	320	12	76.7	1480
260		DS200-150-250C-18.5/4	340	14	77.5	1480
261		DS200-150-250B-22/4	360	16.5	77.7	1480
262		DS200-150-250A-30/4	400	20	82.7	1480
263		DS200-150-250-37/4	400	22	83.1	1480
264		DS200-150-315.1C-37/4	350	26	71.9	1480
265		DS200-150-315.1B-45/4	400	27.5	74.6	1480
266		DS200-150-315.1A-55/4	400	34	73.2	1480
267		DS200-150-315.1-75/4	480	38	78.4	1480
268		DS200-150-315D-37/4	420	21	74.6	1480
269		DS200-150-315C-45/4	480	23	76.1	1480
270		DS200-150-315B-55/4	550	25	78.1	1480
271		DS200-150-315A-75/4	600	32	79.8	1480
272		DS200-150-315-90/4	630	36	81.1	1480
273		DS200-150-400.1C-75/4	400	45	73.7	1480
274		DS200-150-400.1B-90/4	400	52	72.3	1480
275		DS200-150-400.1A-110/4	400	62	71.9	1480
276		DS200-150-400.1-132/4	450	68	72.4	1480
277		DS200-150-400E-55/4	400	32	74.8	1480
278		DS200-150-400D-75/4	500	36	76.1	1480
279		DS200-150-400C-90/4	500	42	76.2	1480
280		DS200-150-400B-110/4	500	50	76.3	1480
281		DS200-150-400A-132/4	550	56	76.7	1480
282		DS200-150-400-160/4	600	63	75.9	1480
283		DS200-150-500C-132/4	400	73	64.5	1480
284		DS200-150-500B-160/4	450	83	67.2	1480
285		DS200-150-500A-200/4	450	92	66.7	1480
286		DS200-150-500-220/4	450	94	66.7	1480
287	DS250-200	DS250-200-400F-37/4	400	22	78.2	1480
288		DS250-200-400E-45/4	450	25	81.2	1480
289		DS250-200-400D-55/4	500	30	82.8	1480
290		DS250-200-400C-75/4	600	37	83.9	1480
291		DS250-200-400B-90/4	630	42	84.5	1480
292		DS250-200-400A-110/4	650	48	84.2	1480
293		DS250-200-400-132/4	700	50	83.7	1480
294		DS250-200-450D-75/4	500	40	74.5	1480
295		DS250-200-450C-90/4	530	46	75.6	1480
296		DS250-200-450B-110/4	550	53	75.8	1480
297		DS250-200-450A-132/4	550	60	76	1480
298		DS250-200-450-160/4	550	69	75.7	1480
299	DS300-250	DS300-250-350D-37/4	700	17	75.7	1480
300		DS300-250-350C-45/4	700	22	78.6	1480
301		DS300-250-350B-55/4	800	23	81.6	1480
302		DS300-250-350A-75/4	800	28	81.6	1480
303		DS300-250-350-90/4	800	31	81.4	1480
304		DS300-250-400E-55/4	630	26	76	1480
305		DS300-250-400D-75/4	750	31	79	1480
306		DS300-250-400C-90/4	800	34	79.5	1480
307		DS300-250-400B-110/4	850	38	79.2	1480
308		DS300-250-400A-132/4	900	41	79.7	1480
309		DS300-250-400-160/4	900	48	80.2	1480
310		DS300-250-450E-75/4	650	32	75.3	1480
311		DS300-250-450D-90/4	700	36	76.1	1480
312		DS300-250-450C-110/4	800	40	78.1	1480
313		DS300-250-450B-132/4	900	45	80	1480
314		DS300-250-450A-160/4	900	50	80.3	1480
315		DS300-250-450-200/4	900	59	79.5	1480
316		DS300-250-500C-160/4	900	50	81.6	1480
317		DS300-250-500B-200/4	900	60	82.3	1480
318		DS300-250-500A-250/4	900	70	82.4	1480
319		DS300-250-500-315/4	900	82	82.1	1480

标签：

上一篇：南元泵业MSP系列浸入式超高压多级离心泵，高压机床行业的首选，配永磁变频电机

下一篇：南元泵业TD/EC系列管道循环泵，便拆式结构，维护便捷，效率高

南元泵业DS系列卧式端吸离心泵参数表，型谱宽，已选型，高效节能

4001 077 588
